CXFORM: Coordinate transformation package for IDL and C

Originally written by Ed Santiago (LANL)
Extended & maintained by Ryan Boller (NASA/GSFC)

Jump to:  Overview   Download   Usage   Coord. Systems Impl.   Misc.


The CXFORM package contains a set of routines to convert spacecraft coordinates
from one system to another, i.e., GSE-->GSM.  It is written in C and can be
used as either a C library (.so or .dll) or as an IDL function on most platforms
(via its DLM -- Dynamically Loadable Module -- interface).

It has been tested under SunOS v5.7, Microsoft Windows 2000/XP, Mac OS X 10.3
& 10.4, and Linux kernel release 2.4.20.  It has previously been tested under
Solaris 2.6 and DEC OSF/1 V4.0.

It is largely based on Mike Hapgood's excellent introduction to coordinate
transformations, along with Markus Fraenz' "Heliospheric Coordinate Systems"
and Christopher Russell's "Geophysical Coordinate Transformations":

Note that since this follows much of Hapgood's formulae that are optimized for
simplicity and efficiency, he specifies a level of precision of 0.001 degrees
up to the year 2100 for each rotation angle, which has been deemed sufficient
for space physics applications.  The disclaimer applies that these should not
be used for mission-critical flight applications due to their margin of error.

Formal testing has been completed as of 2004/12/01.  The results can be found
here on the CXFORM web page.  In general, they are within 1% of the results of
SSCWeb's calculations (based on GEOPACK), and in many cases are within

If you find CXFORM to be useful (or have other comments), please let us know
For one example of CXFORM in a production environment, visit the USGS
EarthNow! Landsat Image Viewer.  By converting satellite positions and
velocities from GEI to GEO, the exact ground track can be computed, enabling
city names and the track itself to be properly located.


Source code:

Precompiled binaries (with source code):
    cxform-0.71_MacOS.tar.gz (Universal)*

* = these libraries were compiled under Mac OS X 10.5 and may not work under
    prior versions. If this appears to be the case, please download the source
    code and compile using instructions in install.txt.  You will need the C
    compiler included in Xcode.

** = contains compiled C library, but does not contain compiled IDL code
    because a Linux machine with IDL installed was not readily available

See install.txt for instructions (also included in above files).


The function prototype is

    new_pos = CXFORM( pos, source_frame, dest_frame, time )

    pos             is a vector of length 3, containing the position
                    in source_frame coordinates. It can also be a 2-D
                    array of size [3, M], where M is the number of points
                    to convert

    source_frame    is an ASCII string naming the source
                    coordinate system, e.g., 'GSE', 'J2000'.  See
                    "Coordinate Systems Implemented" below.

    dest_frame      is also an ASCII string, naming the destination
                    coordinate system.

    time            is "ephemeris seconds past J2000 (1 Jan 2000 12:00)".
                    The "date2es" function converts a standard Gregorian
                    time (mm,dd,yyyy) to Ephemeris Seconds past/before
                    J2000.  See the included "" file for more

    new_pos         is the position, in dest_frame coordinates.

Single-coordinate example:

    IDL> es = date2es(9,30,1999,7,5,0)  ; Sep. 30, 1999 07:05:00 UTC
    IDL> pos = cxform([1,0,0], 'GSE', 'GEO', es)
    IDL> help,pos
    POS             DOUBLE    = Array[3]
    IDL> print,pos
           0.32034915      0.94616669    -0.046314350

Multiple-coordinate example:

    IDL> imp8GEI = fltarr(3, 5)
    IDL> imp8Time = lonarr(5)
    IDL> help, imp8GEI
    IMP8GEI        FLOAT        = Array[3, 5]
    IDL> help, imp8Time
    IMP8TIME    LONG        = Array[5]
    IDL> imp8GEI[*,0] = [-32.562, 20.085, -10.471]
    IDL> imp8GEI[*,1] = [-34.415, 4.229, -6.173]
    IDL> print, imp8GEI
        -32.5620    20.0850        -10.4710
        -34.4150    4.22900        -6.17300
        -27.2210    -12.441        -0.34300
        -9.01000    -23.380         5.39300
         14.1890    -19.583         7.58900
    IDL> imp8Time = [-43200, 43200, 129600, 216000, 302400]
    IDL> imp8GEO = cxform(imp8GEI, 'GEI', 'GEO', imp8Time)
    IDL> print, imp8GEO
       25.418317       28.593709      -10.471000
       10.691414       32.984396      -6.1729999
      -6.5404276       29.205893     -0.34299999
      -20.772292       14.011294       5.3930001
      -22.419840      -9.0648980       7.5890002

Note that if your data is imported as [M, 3] instead of [3, M], you can
transpose it using IDL's TRANSPOSE function:

    IDL> correctArr = fltarr(3, M)
    IDL> correctArr = TRANSPOSE(originalArr)


See main.c included in this package for an example of using CXFORM in C.
See install.txt for instructions on building it on your platform.


The bulk of the testing used SSCWeb's Locator Tabulator as the data source.
As stated in the introduction, this service uses GEOPACK for its calculations.
An included file, tester.c, was used to read in data from SSCWeb and
compare it to the results of CXFORM.  In addition, one data point was used from
the HelioCoords transformation package documentation as a sanity check and also
as a test for the heliospheric systems that are not present in SSCWeb.

ACE data, year 2000, ~40k data points
Geotail data, year 1993, ~40k data points
IMP-8 data, year 2003, ~40k data points
Geocentric S/C Position from HelioCoords documentation, 1 data point


GEI            Geocentric Equatorial Inertial, also known as True
               Equator and True Equinox of Date, True of Date (TOD),
               ECI, or GCI
J2000          Geocentric Equatorial Inertial for epoch J2000.0
               (GEI2000), also known as Mean Equator and Mean Equinox
               of J2000.0
GEO            Geographic, also known as Greenwich Rotating
               Coordinates (GRC), or Earth-fixed Greenwich (EFG)
MAG            Geomagnetic
GSE            Geocentric Solar Ecliptic
GSM            Geocentric Solar Magnetospheric
SM             Solar Magnetic
RTN*           Radial Tangential Normal (Earth-centered)
GSEQ           Geocentric Solar Equatorial
HEE            Heliocentric Earth Ecliptic
HAE            Heliocentric Aries Ecliptic
HEEQ           Heliocentric Earth Equatorial

* = this system has not been implemented/tested and should be treated as such


This package has been designed to allow for easy additions of new coordinate

All you need to do is define one transformation between the new system and any
of the existing ones.  Once you do that, the Perl script will generate code to
convert to all others.  This, of course, means that a working copy of Perl must
be installed.  You will need the IxHash module if it is not already installed.
It can be found at

Here's what you do:

  1. Edit the file cxform-manual.c and add a new function, xxxx_twixt_yyyy,
     where `xxxx' is any existing coordinate frame, and `yyyy' is the new one.

  2. Run "perl cxform-manual.c" from the prompt. This will
     create a new cxform-auto.c with support for your new coordinate system.
  3. Build and install a new CXFORM library as described in install.txt.

  4. Run and test it in IDL/C.  That's it!

If it works, please send me your code.  I will include it in the next
distribution (with appropriate credit to you, of course).


2000/06/21  v0.2   Ed Santiago:  Last released version from Ed.
2003/09/12  v0.3   Ryan Boller:  First modified version from Ryan.  Added RTN
            and GSEQ systems, IGRF model, slightly different time
            manipulation, Windows support, additional documentation, and
            standalone C functionality.
2004/03/19  v0.4  Ryan Boller:  Updated Makefile to auto-detect platform and
            to build under Mac OS X.  HEEQ system now implemented by Kristi
2004/05/21  v0.5  Ryan Boller:  Fixed small discrepancy in calculation of
            T0 and lambda0.  Results now match those of SSCWeb's (GEOPACK-
            based) when the mag pole lat/lon is fixed to their values,
            as they haven't updated their IGRF coefficients.
2004/12/01  v0.6  Ryan Boller: Finished comprehensive testing, posted results.
            Updated IGRF to Revision 9.  Moved cxRound, date2es, and
            gregorian_calendar_to_jd to cxform-manual.c so it is included
            in the shared library.
2006/10/19  v0.7  Ryan Boller: Updated IGRF coefficients to 10th generation.
            Fixed IDL DLM interface under Windows XP & IDL 6.0+. Updated
            installation documentation.
2009/11/25  v0.71  Ryan Boller: Updated Mac compiler flags to compile 32- and
            64-bit versions on Intel- and PPC-based CPUs.  Fixed memory pointer
            problem on 64-bit machines (now using IDL_MEMINT instead of IDL_LONG
            in cxform-dlm.c).


- Mac shared object does not link with C objects.  May need to convert to a
  dylib.  The shared object does work with the IDL DLM interface, though.
- RTN System needs to be tested for accuracy.
